Lua code running inside OpenResty or Nginx servers is very common nowadays since people want both performance and flexibility out of their nonblocking web servers. Some people use Lua for very simple tasks like modifying and checking certain request headers and response bodies while other people use Lua to build very complicated web applications, CDN software, and API gateways. Lua is known for its simplicity, small memory footprint, and efficiency, especially when using Just-in-Time (JIT) compilers like LuaJIT. But still some times the Lua code running atop OpenResty or Nginx servers may consume too much CPU resources due to the programmer’s coding mistakes, calling out to some expensive C/C++ library code, or some other reasons.

The best way to quickly find all the CPU bottlenecks in an online OpenResty or Nginx instance is the Lua-land CPU flame graph sampling tool as provided by the OpenResty XRay product. It does not require any changes to the target OpenResty or Nginx processes nor have any noticeable impact to the processes in production. This article will introduce the idea of Lua-land CPU flame graphs and use OpenResty XRay to produce real flame graphs for several small and standalone Lua examples. We choose small examples because it is much easier to predict and verify the profiling results. The same idea and tools do apply equally well to those most complex Lua applications in the wild. And we have had many successes in using this technique and visualization to help our customers running very busy sites and applications in the past few years.

What is a Flame Graph

Flame graphs are a visualization method invented by Brendan Gregg for showing how a system resource or a metric is distributed across all the code paths in the target software. The system resource could be CPU time, off-CPU time, memory usage, disk usage, latency, or any other things you can imagine. The code paths here are defined by the backtraces in the target software’s code. A backtrace is usually a stack of function call frames as in the output of the bt GDB command and in an exception error message of a Python or Java program. When we say “all code paths”, we actually mean it from a statistical perspective instead of literally iterating through every single code path in a program. Obviously the latter would be prohibitively expensive to do in reality. We just make sure all code paths with nontrivial overhead are showing up in our graphs and we can identify their cost quantitatively with good enough confidence.

In this article we just focus on the type of flame graphs which show how the CPU time (or CPU resources) is distributed across all the Lua code paths in a target OpenResty or Nginx process (or processes), hence the name “Lua-Land CPU Flame Graphs”.

The header picture of this article shows a sample flame graph and we will see several more in later parts of this post.

Why Flame Graphs

Flame Graphs are a great way to show the “big picture” of bottlenecks quantitatively in a single small graph. Traditional profilers would usually throw a ton of details and numbers at the user’s face. And the user may lose insight of the whole picture and go through rabbit holes for things that do not really matter. Another drawback of traditional profilers is that they just give you latencies of all the functions while it’s hard to see the contexts of these function calls, not to mention the user also has to distinguish the exclusive time and inclusive time of a function call. On the other hand, Flame Graphs can squeeze a great deal of information very compactly into a limited size graph. Stuff which do not matter fade out naturally while stuff which really matter would stand out as well. No more, no less, just the right amount of information for the user.

How to read a Flame Graph

Flame Graphs might be a bit tricky to read for a newcomer. But with a little guidance the user would find it so intuitive to understand. A Flame Graph is two-dimensional graph. The y-axis shows the context, i.e., the backtraces of the target programming language while the x-axis shows how much percentage a particular backtrace takes. The full x-axis usually means 100% of the resources spent on the target software. The order of backtraces along the x-axis usually do not matter since they are usually simply sorted by function frame names alphabetically. There are exceptions however, where I invented a type of Time-Series Flame Graphs where the x-axis actually means the time axis instead. For this article, we only care about the classic type of flame graphs where the order along the x-axis does not matter at all.

The best way to learn how to read a flame graph is to read sample flame graphs. We will see several examples below with detailed explanation for OpenResty and Nginx’s Lua applications.

Simple Lua samples

In this section, we will consider several simple Lua samples with obvious performance characteristics and we will use OpenResty XRay to profile the real nginx processes to show Lua-land CPU Flame Graphs and verify the performance behaviors in the graphs. We will check different cases like with and without JIT compilation enabled for the Lua code, as well as calling into external C library code.

JIT compiled Lua code

We will first investigate a Lua sample program with JIT compilation enabled (which is enabled by default in LuaJIT).

Let’s consider the following standalone OpenResty application. We will use this example throughout this section with minor modifications for different cases. We first prepare the applications’ directory layout:

1
2
3
mkdir -p ~/work
cd ~/work
mkdir conf logs lua

And then we create the conf/nginx.conf configuration file as follows:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
master_process on;
worker_processes 1;

events {
worker_connections 1024;
}

http {
lua_package_path "$prefix/lua/?.lua;;";

server {
listen 8080;

location = /t {
content_by_lua_block {
require "test".main()
}
}
}
}

Here we load the external Lua module named test and immediately calls its main function in our Lua handler for the location /t. We use the lua_package_path directive to add the lua/ directory into the Lua module search paths since we will shortly put the aforementioned test Lua module into lua/.

The test Lua module is defined in the lua/test.lua file as follows:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
local _M = {}

local N = 1e7

local function heavy()
local sum = 0
for i = 1, N do
sum = sum + i
end
return sum
end

local function foo()
local a = heavy()
a = a + heavy()
return a
end

local function bar()
return (heavy())
end

function _M.main()
ngx.say(foo())
ngx.say(bar())
end

return _M

Here we define a computation-heavy Lua function, heavy(), which computes the sum of numbers from 1 to 10 million (1e7). Then we call this heavy() function twice in function foo() and just once in function bar(). Finally, the module entry function _M.main() calls foo and bar just for once in turn and print out their return values respectively to the HTTP response body via ngx.say.

Intuitively, for this Lua handler, the foo() function would takes exactly twice of the CPU time taken by the bar() function because foo() calls heavy() twice while bar() only calls heavy() once. We can easily verify this observation in the Lua-land CPU flame graphs sampled by OpenResty XRay below.

Because we did not touch the JIT compiler settings in this example, the JIT compilation is turned on by default since modern OpenResty platform versions always use LuaJIT anyway.

Now we can start this OpenResty web application like this:

1
2
cd ~/work/
/usr/local/openresty/bin/openresty -p $PWD/

assuming OpenResty is installed under /usr/local/openresty/ in the current system.

To make this OpenResty application hot, we can use tools like ab and weighttp to load the URI http://localhost:8080/t or the load generator provided by the OpenResty XRay product. Either way, while the target OpenResty applications’ nginx worker process is busy, we can get the following Lua-land CPU flame graph in OpenResty XRay’s web console:

Lua-land CPU flame graph for JITted Lua code

From this graph we can make the following observations:

  1. All Lua backtraces in this graph stem from the same entry point, content_by_lua(nginx.conf:24), which is expected.

  2. There are mainly two code paths shown in the graph, which are

    1
    content_by_lua -> test.lua:main -> test.lua:bar -> test.lua:heavy -> trace#2:test.lua:8

    and also

    1
    content_by_lua -> test.lua:main -> test.lua:foo -> test.lua:heavy -> trace#2:test.lua:8

    The only difference in these two code paths are foo vs bar. This is also expected.

  3. The left-hand-side code path involving bar is just half as wide as the right-hand-side code path involving foo. In other words, their width ratio along the x-axis is 1:2, which means that the bar code path takes only 50% of the time taken by foo. By putting your mouse onto the test.lua:bar frame (or box) in the graph, we can see that it takes 33.3% of the total samples (or total CPU time) while the test.lua:foo frame shows 66.7%. Obviously it is very accurate as compared to our predictions even though it takes a sampling and statistical approach.

  4. We did not see other code paths like ngx.say() in the graph since such code paths simply take too little CPU time as compared to the two dominating Lua code paths involving heavy(). Trivial things are simply noises which won’ t catch our attention in the flame graph. We always focus on really important things and cannot get distracted.

  5. The top frames for both code paths (or backtraces) are the same, which is trace#2:test.lua:3. This is not a really Lua function call frame, but rather a pseudo frame indicating that it is running a JIT compiled Lua code path which is called “trace” in LuaJIT’s terminology (because LuaJIT is a tracing JIT compiler). And this “trace” has the ID number 2 and the compiled Lua code path starting from the Lua source code line 8 of the test.lua file. test.lua:8 is this Lua code line:

    1
    sum = sum + i

It is wonderful to see our noninvasive sampling tool can get such accurate flame graphs from a standard binary build of OpenResty without any extra modules, modifications, or special build flags. The tool does not use any special features or interfaces of the LuaJIT runtime at all, not even the LUAJIT_USE_PERFTOOLS feature or its built-in profiler. Instead it uses advanced dynamic tracing technologies which simply read the information already available in the target process itself. And we are able to get good enough information even from JIT compiled Lua code.

Interpreted Lua code

Interpreted Lua code can usually result in perfectly accurate backtraces and flame graphs. If the sampling tool can handle JIT-compiled Lua code just fine, then it can only do a better job when dealing with interpreted Lua code. One interesting thing about LuaJIT’s interpreter is that the interpreter is written almost completely in hand-crafted assembly code.

For our continuing Lua example, we simply add the following nginx.conf snippet inside the server {} block:

1
2
3
init_by_lua_block {
jit.off()
}

And then reload or restart the server processes and still keep the traffic load.

This time we get the following Lua-land CPU flame graphs:

Lua-land flame graph for interpreted Lua code

This graph is very similar to the previous one in that:

  1. We are still only seeing two main code paths, the bar one and the foo one.
  2. The bar code path still takes approximately one third of the total CPU time and the foo one still takes the remaining two-thirds.
  3. The entry point for all the code paths shown in the graph is the content_by_lua thing.

This graph still has an important difference, however: the tips of the code paths (or backtraces) are no longer “traces”. This is expected since no JIT compiled Lua code paths are possible this time. The tips or top frames are now C function frames like lj_BC_IFORL and lj_BC_ADDVV. These C functions frames are actually not C functions per se. Instead they are assembly code frames corresponding to LuaJIT byte code interpretation handlers specially annotated by symbols like lj_BC_IFORL. Naturally, lj_BC_IFORL is for the LuaJIT byte code instruction IFORL while lj_BC_ADDVV is for the byte code instruction ADDVV. The IFORL is for interpreted Lua for loops while ADDVV is for arithmetic additions. All these are expected according to our Lua function heavy(). There are also some auxiliary assembly routines like lj_meta_arith and lj_vm_foldarith. By looking at the percentage numbers for these frames, we can also understand how the CPU time is distributed across inside the LuaJIT virtual machine and interpreter, paving the way to optimize the VM and the interpreter themselves.

Calling external C/C++ functions

It is very common for Lua code to invoke external C/C++ library functions, in which case we also want to see their proportional parts in the Lua-land CPU flame graphs. Because such C function calls are initiated from within the Lua code anyway. This is also where dynamic-tracing-based profiling really shines where such external C function calls would never become the blind spots for the profiler[1].

Let’s modify the heavy() Lua function in our ongoing example as follows:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
local ffi = require "ffi"
local C = ffi.C

ffi.cdef[[
double sqrt(double x);
]]

local function heavy()
local sum = 0
for i = 1, N do
-- sum = sum + i
sum = sum + C.sqrt(i)
end
return sum
end

Here we use LuaJIT’s FFI API to declare and invoke the standard C library function sqrt() directly from within the Lua function heavy(). It should show up in the corresponding Lua-land CPU flame graphs.

This time we got the following flame graph:

Lua-land flame graph for Lua code calling C functions

Interestingly we indeed see the C function frame C:sqrt showing up as the tips of those two main Lua code paths. It’s also worth noting that we still see the trace#N frames near the top, which means that our FFI calls into the C function can also be JIT compiled (this time we removed the jit.off() statement from the init_by_lua_block directive).

Line-Level Flame Graphs

The previous flame graphs we have seen are all function-level flame graphs because almost all the function frames shown in the flame graphs have only function names instead of the source lines initiating the calls.

Fortunately OpenResty XRay’s Lua-land profiling tools can also generate Lua source line numbers in its line-level flame graphs by which we can easily know exactly what Lua source lines are hot. Below is such an example for our ongoing Lua example:

Line-level Lua-land flame graph for JITted Lua code

We can see that there are now one more source-line frame added above each corresponding function name frame. For example, inside function main, on the line 32, there comes the call to the foo() function. And inside the foo() function, on line 22, there is the call to the heave() function, and etc.

Line-level flame graphs are very useful to pinpoint the hottest source line and Lua statements. This can save a lot of time when the corresponding Lua function body is large.

Multiple processes

It is common to configure multiple nginx worker processes for a single OpenResty or Nginx server instance on a system with multiple CPU cores. OpenResty XRay’ s profiling tools support sampling all the processes in a specific process group at the same time. This is useful when the incoming traffic is moderate and is spread across arbitrary nginx worker processes.

Complicated Lua applications

We can also get Lua-land CPU flame graphs from very complicated OpenResty/Lua applications in the wild. For example, below is a Lua-land CPU flame graph sampled on one of our mini-CDN server running our OpenResty Edge product, which is a very complex Lua application, including a dynamic CDN gateway, a geo-sensitive DNS server, and a web application firewall (WAF):

Lua-land CPU flame graph for our mini-CDN server

From this graph, we can see that the WAF takes most of the CPU time while the built-in DNS server also takes a good portion. Our global mini-CDN network is also powering our own web sites like openresty.org and openresty.com.

It can surely analyze OpenResty-based API gateway software like Kong as well.

Sampling overhead

Because we use the sampling approach instead of full instrumentation, the overhead involved with the sampling for generating Lua-land CPU flame graphs is usually negligible which makes such tools usable in production or online environments.

If we load the target nginx worker process with requests of a constant rate, the CPU usage curve of the target process while Lua CPU flame graph sampling is frequently performed is like this:

CPU usage curve when sampling

This CPU usage line graph is also generated and rendered by OpenResty XRay automatically.

And then we stop sampling at all and the CPU usage curve of the same nginx worker process is very similar:

CPU usage for processes when not sampling

We cannot really see any differences between these two curves with human eyes. So the profiling and sampling cost is indeed very small.

When the tools are not sampling, the performance impact is strictly zero since we never change anything in the target processes anyway.

Safety

Because we use dynamic tracing technologies, we do not change any state in the target processes, not even a single bit of information[2]. This makes sure that the target process behaves (almost) exactly the same as the case when no sampling is performed. This guarantees that the target process’s reliability and behaviors won’t get compromised by the profiling tool. They stay exactly the same as when no one is watching, just like taking an X-ray image against a live animal. Traditional Application Performance Manager (APM) products may require loading special modules or plugins into the target software, or even bloodily patching or injecting binary code into the target software’s executable or process space, severely compromising the stability and correctness of the user systems.

For these reasons, these tools are safe to use in production environments to analyze those really hard problems which cannot be easily reproduced offline.

Compatibility

The Lua-land CPU flame graph sampling tool provided by the OpenResty XRay product supports any OpenResty or Nginx binaries including those compiled by the users themselves with aribitrary build options, optimized or unoptimized, using the GC64 mode or non-GC64 mode in the bundled LuaJIT library, and etc.

OpenResty and Nginx server processes running inside Docker or Kubernetes containers can also be analyzed transparently by OpenResty XRay and perfect Lua-land CPU flame graphs can be rendered without problems.

Our tool can also analyze console-based user Lua programs run by the resty or luajit command-line utilities.

Other types of Lua-land Flame Graphs

As mentioned earlier in this post, flame graphs can be used for visualizing any system resources or metrics, not just CPU time. Naturally we do have other types of Lua-land flame graphs in our OpenResty XRay product, like off-CPU flame graphs, garbage collectable (GC) object size and data reference path flame graphs, new GC object allocation flame graphs, Lua coroutine yielding time flame graphs, file I/O latency flame graphs, and many more. We will cover these different kinds of flame graphs in future articles on our blog site.

Conclusion

In this article we introduce the very useful visualization, Flame Graphs, for profiling software performance. And we have a deep look at one particular type of flame graphs, Lua-land CPU Flame Graphs, for profiling Lua applications running atop OpenResty and Nginx. We investigate several small Lua sample programs using real flame graphs produced by OpenResty XRay to demonstrate the strength of our sampling tools based on dynamic tracing technologies. Finally we look at the performance overhead of sampling and the safety of online uses.

About The Author

Yichun Zhang is the creator of the OpenResty® open source project. He is also the founder and CEO of the OpenResty Inc. company. He contributed a dozen open source Nginx 3rd-party modules, quite some Nginx and LuaJIT core patches, and designed the OpenResty XRay platform.

Translations

We will provide a Chinese translation for this article on blog.openresty.com.cn. We also welcome interested readers to contribute translations in other natural languages as long as the full article is translated without any omissions. We thank them in advance.
