OpenResty Edge offers powerful Lua extension capabilities. This video uses the example of automatically handling abnormal offline situations of gateway servers to provide a detailed introduction on how to create and configure Lua extensions in Edge’s Web console. The goal is to automatically remove corresponding nodes from GoDaddy when a gateway server goes offline.

Create a new Lua extension

OpenResty Edge provides powerful Lua extensions to automatically respond to offline events from the gateway server.

Let’s switch to the web console of OpenResty Edge. This is our sample deployment of the console. Every user would have their own deployment.

Go to the “Global Config” page.

Click on “Global Lua Extensions”.

Let’s create a new Lua Extension.

Create an extension to prevent GoDaddy from resolving a domain name to an already offline node.

Here we enter the name as “remove_node_from_godaddy_if_node_is_offline”.

Select “By event”.

OpenResty’s Edge supports several kinds of built-in events.

Here, we select the type “Gateway Server Abnormal Offline”. This means that if the server is offline, the Lua Extension will be triggered.

If you are used to using Vim, you can enable Vim mode to edit code.

When the event occurs, it will pass trigger_event to Lua Extension.

Send a request to the manager service, which could remove the node from GoDaddy when it’s offline.

When the response content meets the conditions, use Lua’s cjson module to decode it and assign the result to the body variable.

If body exists and body.status equals 0, then output the successful message.

Click to create it!

Trigger the Lua extension with an offline gateway server

After creating, the new Lua Extension will work automatically. Let’s test it with an offline gateway server.

Go to Gateway Clusters’s page.

This is the gateway cluster we are going to use.

It’s online now.

Use the systemctl command on the terminal to stop the service.

Refresh the list.

The server is offline now.

Go back to “Global Config”.

Enter “Global Lua Extensions”.

Check the history of execution.

As shown, the extension has been triggered and executed.

The node has been removed from GoDaddy successfully.

What is OpenResty Edge

OpenResty Edge is our all-in-one gateway software for microservices and distributed traffic architectures. It combines traffic management, private CDN construction, API gateway, security, and more to help you easily build, manage, and protect modern applications. OpenResty Edge delivers industry-leading performance and scalability to meet the demanding needs of high concurrency, high load scenarios. It supports scheduling containerized application traffic such as K8s and manages massive domains, making it easy to meet the needs of large websites and complex applications.

If you like this tutorial, please subscribe to this blog site and/or our YouTube channel. Thank you!
